220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine

Product Categories
Shijiazhuang Zhongtai Pipe Technology Development Co., Ltd
Contact Now

220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine

  • 1
  • 2
  • 3

Brand Name : ZTZG

Model Number : SS50

Certification : ISO9001/CE

Place of Origin : Hebei, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets/year

Delivery Time : 120 days

Packaging Details : All mechanical equipment is nude packing and electrical parts are packed in wooden cases

Applicable Industry : Hotels, Garment Shops, Building Material Shops, Manufacturing

After Warranty Service : Video technical support, Online support, Spare parts

Marketing Type : New Product 2021

Warranty of core : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor

Condition : New

Type : Pipe Mill

Pipe Material : stainless steel

Application : Manufacturing Plant, Construction works

Production Capacity : 1-15m/min

Voltage : 220/380/415/440V

Contact Now

Square Tube Mill Sales To Malaysia Mill Line Decorative Stainless Steel Tube Mill

Product Description

Stainless steel industry control machine stainless steel tube machine is mainly used for industrial stainless steel pipe, water pipe, natural gas, nuclear power generation tube manufacturing, due to the stainless steel welded pipe technology mature, in many areas has made seamless tube (e.g., chemical, pharmaceutical, brewery, oil, food, automobile, papermaking, air conditioning industry and widely used)..

Model Horizontal axis diameter (mm) Vertical shaft diameter (mm) Pipe diameter (mm) Pipe thickness (mm) Main motor power (dual) Mechanical assembly size (length X width)
SS40 40 25 8-51 0.5-2.0 Before 7.5 KW 29m X 1.5m
After the5.5KW
SS50 50 30 25-63 0.5-3.0 Before 11KW 32m X 1.5m
After the7.5KW
SS60 60 40 50-114 0.6-3.5 Before 15 KW 35m X 1.8m
After the15KW
SS80 80 50 89-168 1.0-4.5 Before 18.5 KW 40m X 2.5m
After the18.5 KW
SS100 100 60 114-219 1.0-5.0 Before 22 KW 43m X 3.0m
After the22KW
Industrial pipe machine machinery main components: uncoiler, forming welding machine, grinding machine, two sizing unit, straight frame, cutting machine, finished frame

220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine

ZTZG Company Introduction
220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine
220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine
220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine
220/380V 50mm Square Tube Mill Line Industrial Pipe Making Machine

FAQ

Q: Are you a manufacturer?
A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
Q: What kind of payment term do you do?
A: We do T/T.
Q: What info do you need before giving me the price and proposal?
A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
Q: What should I do if I just start a new business?
A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
Q: How do you do QA?
A: We have a special team to do strict QA, this is one of our strengths:
(1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

(2)Every shaft will be inspected for centering jumpiness.
(3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the middle east, Europe, and South America throughout the years. Our innovative designed production line and every single unit of the production line are economical and practical.

Model List
Model Round pipe Square pipe Thickness Working spead
mm mm mm m/min
SS25 Ф6-Ф25 5x5-20x20 0.2-0.8 10
SS32 Ф6-Ф32 5x5-25x25 0.2-1.0 10
SS51 Ф9-Ф51 7x7-40x40 0.2-1.5 10
SS64 Ф12-Ф64 10x10-50x50 0.3-2.0 10
SS76 Ф25-Ф76 20x20-60x60 0.3-2.0 10
SS114 Ф38-Ф114 30x30-90x90 0.4-2.5 10
SS168 Ф76-Ф168 60x60-130x130 1.0-3.5 10
SS219 Ф114-Ф219 90x90-170x170 1.0-4.0 10
SS325 Ф219-Ф325 170x170-250x250 2.0-8.0 3
SS426 Ф219-Ф426 170x170-330x330 3.0-10.0 3
SS508 Ф273-Ф508 210x210-400x400 4.0-12.0 3
